NI PXIE-7961R High-Density Multichannel Digitizer Module

In stock

The NI PXIE-7961R is a high-performance FPGA module designed for real-time data acquisition and processing in industrial automation systems. Its versatile architecture allows it to be seamlessly integrated into various industrial control applications, offering unparalleled speed and reliability.

Module Type:High-Speed Digital I/O

Channels:Up to 32 Channels

Voltage Range:±10V

Maximum Sample Rate:Up to 100 MS/s

Resolution:16 bits

Connectivity:PCI Express

Dimensions:Standard PXI Express slot size

Operating Temperature:-40°C to +85°C

Certification:Compliant with IEEE 1588 Precision Time Protocol

The National Instruments PXIe-7961R FPGA Module is a leading-edge solution for those requiring real-time processing capabilities in their automated test equipment or data acquisition systems. It features a Xilinx Kintex UltraScale KU060 FPGA that provides unparalleled flexibility and performance, enabling developers to create custom logic designs tailored to their specific application needs.

With its PCI Express x4 interface, this module can transfer data at speeds up to 2 GB/s, ensuring seamless integration with other PXI Express modules and systems. Additionally, the inclusion of 8 GB DDR4 RAM allows for efficient data handling and complex computations.

Engineered for durability and reliability, the PXIe-7961R operates within a wide temperature range of -40°C to +85°C, making it suitable for challenging environments. It requires a stable 12 V DC power supply at 5 A, which is easily managed through standard PXI Express backplane connections.

This FPGA module is perfect for applications such as aerospace and defense, automotive testing, telecommunications, and scientific research where precise and rapid data processing is critical. With National Instruments’ commitment to quality and support, the PXIe-7961R stands out as a top choice for advanced system design.

NI PXIE-7961R
