Manufacturer:General Electric
Model Number:DS3800NFCF1J1E
Series:Mark IV
Type:Turbine Control Firing Board
Circuits:42
RAM:8-bit static MOS RAM chips with an internal address latch and a minimum access time of 400ns
Counters:4-bit up/down counters with fully independent clear input
Flip-Flops:Dual J-K negative-edge-triggered flip-flops fully buffered for maximum isolation
Switches:Two push-button switches labeled ‘step’ and ‘reset’
LEDs:Two sets of LEDs for status indication
Alignment:Alignment marked (A-L) and factory drilled
Pins:Supported by four nylon pins
Compatibility:Works with DS3800NFCF1F1E board
The DS3800NFCF1J1E is meticulously engineered for precision control within GE’s Mark IV turbine control systems. Designed specifically for gas and steam turbine environments, this board offers unparalleled reliability and performance. Its core features include 8-bit static MOS RAM chips with an internal address latch, providing rapid data processing capabilities. With 42 circuits, it efficiently manages various control tasks, ensuring optimal operation under demanding conditions. The inclusion of 4-bit up/down counters and dual J-K negative-edge-triggered flip-flops enhances its functionality, offering robust and reliable performance.
This board is equipped with two push-button switches labeled ‘step’ and ‘reset’, allowing operators to manually intervene in the control process if necessary. Two sets of LEDs provide visual feedback on the board’s operational status, aiding in quick diagnostics and maintenance. The DS3800NFCF1J1E is marked for alignment and factory-drilled, ensuring accurate installation every time. Additionally, supported by four nylon pins, it maintains stability and durability even in harsh industrial settings. Its compatibility with the DS3800NFCF1F1E board ensures seamless integration within existing systems.
